ETO Sterilizer

• Chamber Size
• 200 litre

• Chamber Thickness
• 4-6 mm

• Compressed Air
• Required for operation

• Design Pressure
• 1.2 kg/cm2

• Design Temperature
• Up to 60C

• Door Type
• Manual/Automatic

• Heat Uniform
• 2C variation

• Inner Trolley
• Available

• Insulation
• PUF/Glass wool

• Net Weight
• Approx. 240 kg

• Outer Size
• Custom as per model

• Outer Trolley
• Provided, stainless steel

• Piping System
• 316/304 Stainless Steel

• Power Consumption
• ~3-4 kW

• Recording Parameters
• Digital display & print

• Spraying Mode
• Automatic circulation

• Spraying Piping
• Stainless Steel

• Steam
• Required for sterilization

• Sterilization Time
• 2-4 hours

• Sterilizing Temperature
• 37C to 57C

• Temperature Scope
• Custom programmable

• Type
• Other, ETO Sterilizer

• Valves
• High precision

• Working Pressure
• 1.0 kg/cm2

• Working Temperature
• Up to 57C

• Chamber Size
• 125 L

• Chamber Thickness
• Rugged Construction

• Design Pressure
• Positive Pressure

• Design Temperature
• 55C

• Door Type
• Manual/Automatic

• Heat Uniform
• Uniform Distribution

• Insulation
• Thermal Insulation

• Piping System
• Corrosion-resistant

• Power Consumption
• Low Power

• Recording Parameters
• Digital Display

• Spraying Mode
• Gas Circulation

• Spraying Piping
• Stainless Steel

• Sterilization Time
• 60-180 minutes

• Sterilizing Temperature
• 37C to 55C

• Temperature Scope
• Up to 55C

• Type
• Other, ETO Sterilizer

• Valves
• Gas Valves

• Working Pressure
• 0.5 to 1 kg/cm2

• Working Temperature
• Up to 55C

• Chamber Size
• 450 liters

• Chamber Thickness
• 5 mm, SS 304

• Compressed Air
• 6-8 kg/cm2

• Design Pressure
• 2.5 kg/cm2

• Design Temperature
• 60C

• Door Type
• Single/Double Hinged Door

• Heat Uniform
• 3C

• Inner Trolley
• Removable, stainless steel

• Insulation
• High-density mineral wool

• Net Weight
• Approx. 850 kg

• Outer Size
• Custom, approx. 1600x1200x1800 mm

• Outer Trolley
• Provided with set

• Piping System
• Corrosion-resistant SS 304

• Power Consumption
• 4 kW (approx.)

• Recording Parameters
• Digital display & print

• Spraying Mode
• Automated misting

• Spraying Piping
• SS 304 spray bars

• Steam
• Steam line provisioning

• Sterilization Time
• 2-6 hours

• Sterilizing Temperature
• 37C to 55C

• Temperature Scope
• Ambient to 60C

• Type
• Other, ETO Sterilizer

• Valves
• Pneumatically actuated

• Working Pressure
• Approx. 1.2 kg/cm2

• Working Temperature
• 40C to 55C

• Chamber Size
• Theoretical 35 L (Approx. 400 mm x 550 mm H)

• Chamber Thickness
• 4-6 mm SS 304

• Compressed Air
• Not Required for Operation

• Design Pressure
• 2.2 bar (Approx.)

• Design Temperature
• Up to 140C

• Door Type
• Single Hinged Radial Locking Lid

• Heat Uniform
• 2C

• Inner Trolley
• Stainless Steel Perforated Trolley

• Insulation
• Glass Wool/Polyurethane Foam

• Net Weight
• Approx. 120 kg

• Outer Size
• 450 mm x 850 mm (Approx)

• Outer Trolley
• Available, Stainless Steel

• Piping System
• SS 304

• Power Consumption
• 220V/240V, 2.5-4 kW (Depending on Model & Configuration)

• Recording Parameters
• Digital Display for Temperature and Time

• Spraying Mode
• Rotational or Static Spray

• Spraying Piping
• SS 304, Stainless Steel

• Steam
• Direct Steam Supply or Built-in Steam Generator

• Sterilization Time
• Adjustable, 0-99 minutes

• Sterilizing Temperature
• 121C - 134C

• Temperature Scope
• Ambient to 134C

• Type
• Other, Vertical Autoclave/Bottle Sterilizer

• Valves
• SS 304, Safety, Exhaust, Vacuum Breaker, Steam Inlet

• Working Pressure
• 1.2-1.5 bar

• Working Temperature
• 121C Standard, Up to 134C Max

• Chamber Size
• 350mm x 400mm x 350mm (Approx. 50 Litres)

• Chamber Thickness
• 3 mm (Inner SS304)

• Compressed Air
• Not Required (Fully Automated System)

• Design Pressure
• -0.90 bar to +2 bar

• Design Temperature
• Up to 60C

• Door Type
• Manual Hinged Door with Silicone Gasket

• Heat Uniform
• 1C Across Chamber

• Inner Trolley
• Removable SS Wire Basket

• Insulation
• Puff Insulated Cabinet

• Net Weight
• Approx. 65 kg

• Outer Size
• 650mm x 750mm x 750mm (Approx)

• Outer Trolley
• Not Available for Tabletop Model

• Piping System
• All Contact Parts SS 304

• Power Consumption
• 800 W (Approx)

• Recording Parameters
• Digital Display with Cycle Data Logging

• Spraying Mode
• Automatic Spraying/Injection

• Spraying Piping
• Stainless Steel 304 Piping for ETO Distribution

• Steam
• Optional Pre-conditioning with Built-in Steam Generator

• Sterilization Time
• 2 to 6 Hours Depending on Load and Cycle

• Sterilizing Temperature
• 37C to 57C (Adjustable)

• Temperature Scope
• Ambient to 57C

• Type
• Other, Tabletop ETO Sterilizer

• Valves
• SS 304 Automatic Operated Solenoid Valves

• Working Pressure
• Atmospheric to 2 bar

• Working Temperature
• Up to 57C
